LED Strip Motion Sensor Module - PIRSM-T10

Product Description

LED Strip motion sensor module detects the approaching person and activates attached LED Strip light.

The human body is an infrared detection sensor switch controller. It uses infrared detection to turn on/off low voltage LED lighting (12/24VDC). Upon person approach towards the sensor within 11.5 feet (3.5 meter) area, the sensor acts as a switch. It turn on the attached optional LED lighting. After a person leaves the sensor area, the Low Voltage Motion Sensors will turn off automatically according to the set time delay.

Note: For use only with Low voltage Class 2 10mm wide single color 12VDC and 24VDC LED Driver Models.

Features

Motion Sensors Switch (Human body infrared sensor)

Dimension: L55 X W11 mm (2.16″ x 0.43″)

Detection distance area: 11.5 feet (3.5 meter)

Compatible with 12/24VDC 10mm wide single color LED Strip light and class 2 power driver

Motion Sensors Detection area

Technical Specifications

Voltage	12/24VDC Class 2 regulated power source
Output	1 Channel
Detection Distance Area	3.5 meter (11.5ft)
Approach Angle	100 degrees
Output Current	<5A
Time Delay	15 seconds to 1 Hour (adjustable)
Operating Environment	-20°C~ 60°C (-4°F ~ 140°F) indoor use only (dry location)
